1.1" 10MP
产品详情
|
型号 Model No. |
焦距 EFL |
最大光圈 F No. |
靶面尺寸 Format Size |
工作距离 Working Distance |
TV畸变 Distortion（TV) |
视场角度(对角*水平*垂直) AFOV(D*H*V) |
滤镜螺纹 Filter size |
||
| 1.1" | 1" | 2/3" | |||||||
| FA66A08 | 8mm | F2.8 | 1.1" | 0.1m-∞ | <0.4% | 93.6°*82°*67.7° | 88°*75.3°*60.1° | 67.4°*55.9°*43.4° | M72-P0.75 |
| FA66A12 | 12mm | F2.2 | 1.1" | 0.1m-∞ | <0.26% | 72.4°*60.4°*49.2° | 67.3°*56°*43.5° | 49.2°*40.3°*30.8° | M37.5-P0.5 |
| FA66A16 | 16mm | F1.8 | 1.1" | 0.2m-∞ | <0.22% | 57.8°*47.8°*38.4° | 53.7°*43.9°*33.6° | 38.4°*31°*23.5° | M37.5-P0.5 |
| FA66A25 | 25mm | F1.4 | 1.1" | 0.2m-∞ | <0.24% | 38.2°*30.9°*24.6° | 34.8°*28.2°*21.3° | 24.4°*19.5°*14.7° | M30.5-P0.5 |
| FA66A35 | 35mm | F1.6 | 1.1" | 0.15m-∞ | <0.03% | 29.1°*23.5°*18.6° | 26.5°*21.4°*16.1° | 18.3°*14.8°*11.1° | M34-P0.5 |
| FA66A50 | 50mm | F2.2 | 1.1" | 0.4m-∞ | <0.06% | 18.2°*14.6°*11.5° | 16.6°*13.3°*10° | 11.5°*9.2°*6.9° | M30.5-P0.5 |
| FA66A75 | 75mm | F2.6 | 1.1" | 0.6m-∞ | <0.03% | 14.2°*11.4°*9° | 12.9°*10.4°*7.8° | 8.9°*7.1°*5.4° | M34-P0.5 |
